DEWALT 20V Max Xr Rotary Hammer Drill, L-Shape Sds Plus, 1-1/8-Inch, Tool Only
DCH293B
The 20V MAX* XR® Brushless 1-1/8 in. Rotary Hammer is a high-performance drill powered by a brushless motor and a durable German-engineered mechanism, delivering 3.5 Joules of impact energy. The lightweight design makes this rotary hammer ideal for structural connections, beam & column anchorage, rod hanging, seismic & safety attachments, cable tray & strut mounting, and steel stanchion mounting. It is part of the PERFORM and PROTECT product line, integrated with the Anti-Rotation E-CLUTCH® System and the SHOCKS ACTIVE VIBRATION CONTROL® System. E-CLUTCH protects the user in bind-up situations by stopping the rotation of the bit. SHOCKS® reduces vibration felt by the user at the handles, compared to rotary hammers without this feature. This hammer becomes OSHA Table 1 Compliant when used with the DWH304DH On Board Extractor.
-
- Cordless hammer drill featuring 3.5 Joules of impact energy provides corded power without the cord
- DEWALT 2V hammer drill features E-Clutch for maximum control in bind-up situations - A Perform and Protect feature.
- DEWALT built brushless motor for all day runtime and durability
- Dust Management Ready. Use with D2534DH.
- German Engineered for Quality and Durability
- Retractable utility hook for convenient hanging
- SHOCKS - Active Vibration Control of DEWALT 2V brushless hammer drill reduces vibration felt by the user at the handles. A Perform and Protect feature.
-
App Compatibility:NoBattery Included:falseBattery Type:20V MAX* Lithium IonBattery Amp Hours:6 AhCharger Included:falseChuck Size:1-1/8-inChuck Type:SDS-PlusCordless vs Corded:CordlessMax RPM:1000 RPMMotor Type:BrushlessProduct Application:DRILLINGDiameter:0.179Height:10.63 INLength:15.5 INWeight:9.15 LBWidth:4.3 INVoltage:20 VWatt Hours:120
Includes:
(1) DCH293 Rotary Hammer,(1) 360 Degree Side Handle,(1) Depth Rod
* Maximum initial battery voltage (measured without a workload) is 20 volts. Nominal voltage is 18.
