DEWALT Dust Extractor For Dch263 Rotary Hammer, D-Handle, 1-1/8-Inch
DWH205DH
The DWH205DH is an OSHA Table 1 Compliant dust extractor for the DCH263 20V MAX* XR® Brushless 1-1/8 in. D-Handle SDS Plus Rotary Hammer. This dust extraction system features a powerful built in motor for increased suction and high-performance drilling. The 2-second power-off delay ensures that dust extraction continues after drill is switched off. The DWH205DH features three nozzle heads for maximum dust collection during the application. The included nozzles are tuned for up to 1 in. diameter bits, all stop bits up to 1.5 in. shoulder and small diameter bits up to 0.5 in. This dust extractor allows for bit lengths up to 10 in. in overall length for drilling applications. This allows users to install a wide range of anchors including pinch nails, rod hanging systems like dropins, large diameter sleeve, stud/wedge, and screw anchors. This unit includes an OSHA 1926.1153-compliant Dust Box Assembly. Equipped with a filter cleaning mechanism and a HEPA filter, it removes 99.97% of airborne particles 0.3 microns or greater.
-
- Compact inline design; Rotary hammer and dust collection only 3.72-inch wide installed.
- DEWALT dust extractor bit lengths up to 1-inch in overall length
- Durable clear high capacity dust box with replaceable HEPA cannister that removes 99.97% of airborne particle .3 microns or greater.
- Dust extractor mounted LED for illuminating low light work environments.
- Easily adjusted depth stop for accurate anchor hole depths
- Quick release for easy tool assembly and disassembly
- Table 1 OSHA 1926.1153-compliant
- Three replaceable optimized dust nozzle heads of the dust extractor are tuned for up to 1-inch diameter bits, all stop bits up to 1.5-inch shoulder and small diameter bits up to .5-inch
-
Battery Included:
false
Cordless vs Corded:
Cordless
Motor Type:
Brushless
Product Application:
DRILLING
Height:
4.250 IN
Length:
19.500 IN
Weight:
4.500 LB
Width:
10.125 INIncludes:
DWH205DH, Dust extractor for the DCH263 20V MAX XR Brushless 1-1/8 in. D-Handle SDS Plus Rotary Hammer.|DWH302DH, Table 1 OSHA 1926.1153-compliant dust box assembly.|Three dust nozzle heads for up to 1" diameter bits, all stop bits up to 1.5 in. shoulder and small diameter bits up to ½ in.
